Specificaties | | Ja |
| |
Aansluitingen | USB 3.0 poort(en) | 4 |
| | USB 2.0 poort(en) | 2 |
| | Aantal HDMI-poorten | 1 |
| | Microfoon, line-in ingang | Ja |
| | Headphone ouputs | 1 |
| | Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| | DVI poort | Nee |
| | Aantal DisplayPorts | 1 |
| | Aantal COM-poorten | 1 |
| | Aansluiting voor netstroomadapter | Ja |
| | Infrarood datapoort | Ja |
| | Hoofdtelefoonuitgangen | 1 |
| | Aantal USB 3.0 (3.1 Gen 1)-poorten | 4 |
| |
Andere features | Aantal geïnstalleerde processoren | 1 |
| |
Audio | Audio output channels | 5.1 |
| | Intel HD Audio Technology | Ja |
| | Intel® High Definition Audio (Intel® HD Audi | Ja |
| | Audio-uitgangskanalen | 5.1 |
| |
Besturingssysteem/software | Inclusief besturingssysteem | Nee |
| |
Design | Type behuizing | USFF |
| | Type koeling | Active |
| | Kleur van het product | Black |
| | Housing material | Metal |
| | Producttype | Mini PC barebone |
| | Materiaal behuizing | Metal |
| | Kabelslot sleuf type | Kensington |
| | Bevestigingsmogelijkheid voor kabelslot | Ja |
| | Aan/uitschakelaar | Ja |
| | LED-indicatoren | HDD, Power |
| |
Eisen aan de omgeving | Temperatuur, in bedrijf | 0 - 40 °C |
| |
Energie | Soort voeding | External AC adapter |
| | Aantal voedingen | 1 |
| | AC invoer voltage | 220-240 V |
| | AC invoer frequentie | 50/60 Hz |
| | AC adapter uitgangsspanning | 12-19 V |
| |
Geheugen | Geheugen slots type | SO-DIMM |
| | Number of memory slots | 1 |
| | Maximum intern geheugen | 8 GB |
| | Supported memory clock speeds | 1333, 1600 MHz |
| | Ondersteunde geheugen types | DDR3L-SDRAM |
| | Geheugen voltage | 1.35 V |
| | Geheugen bandbreedte (max) | 25.6 GB/s |
| | Geheugen kanaal ondersteuning | Single |
| | Aantal geheugenslots | 1 |
| |
Gewicht en omvang | Width | 130 mm |
| | Depth | 128.5 mm |
| | Height | 26 mm |
| | Breedte | 130 mm |
| | Diepte | 128.5 mm |
| | Hoogte | 26 mm |
| |
Grafisch | Ingebouwde grafische adapter | Ja |
| | Graphics adapter | HD Graphics 4400 |
| | Grafische adapter | HD Graphics 4400 |
| | Grafische adapter-familie | Intel |
| |
Inhoud van de verpakking | Inclusief AC adapter | Ja |
| | Netsnoer opgenomen | Ja |
| | Meegeleverde drivers | Ja |
| |
Moederbord | Processorsocket | BGA1168 |
| | Compatibele processors | Core i5 |
| | Aantal ondersteunde processors | 1 |
| |
Netwerk | LAN met kabels | Ja |
| | Bluetooth | Nee |
| |
Opslagmedia | Aantal opslagkaarten ondersteund | 1 |
| | Opslag schijfinterface | mSATA |
| | Opslagkaarten afmetingen ondersteund | 2.5 " |
| | Ondersteunde types opslag-drives | SSD |
| |
Prestatie | Ondersteunt Linux | Ja |
| | Ondersteunt Windows | Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 8 |
| | Maximum resolutie | 3840 x 2160 pixels |
| | Aantal displays ondersteund | 3 |
| |
Processor | L3 cache | 3 MB |
| | Thermal Design Power (TDP) | 15 W |
| | Processor aantal threads | 4 |
| | Turbo-frequentie (max) | 2.6 GHz |
| | Aantal processorkernen | 2 |
| | Processor-productieproces | 22 nm |
| | Processorsocket | BGA1168 |
| | Maximaal ondersteunde CPU kloksnelheid | 2.6 GHz |
| | Compatibele processors | Core i5 |
| | Aantal ondersteunde processors | 1 |
| | Processor kloksnelheid | 1.6 GHz |
| | Processor model | i5-4200U |
| | Processorfamilie | Intel |
| |
Processor speciale functies | Intel Secure Key | Ja |
| | Intel Smart Connect Technology | Ja |
| | Intel ME Firmware-versie | 9.5 |
| | Execute Disable Bit | Ja |
| | Intel Identity Protection Technology | Ja |
| | Thermal Monitoring Technologies | Ja |
| | Enhanced Intel SpeedStep Technology | Ja |
| | Idle States | Ja |
| | Intel 64 | Ja |
| | Intel VT-x with Extended Page Tables (EPT) | Ja |
| | Intel Hyper-Threading Technology | Ja |
| | Intel Turbo Boost Technology | 2.0 |
| | Intel Clear Video HD Technology | Ja |
| | Intel Wireless Display Technology | Ja |
| | Intel Insider | Ja |
| | Intel InTru 3D Technology | Ja |
| | Intel Quick Sync Video Technology | Ja |
| | Intel AES New Instructions | Ja |
| | Intel Anti-Theft Technology | Ja |
| | Intel Rapid Storage Technology | Ja |
| | Intel Virtualization Technology | VT-x |
| | Intel® Secure Key | Ja |
| | Intel® Smart Connect Technology | Ja |
| | Intel® Identity Protection Technology (Intel� | Ja |
| | Intel® 64 | Ja |
| | Intel® VT-x with Extended Page Tables (EPT) | Ja |
| | Intel® Hyper Threading Technology (Intel® HT | Ja |
| | Intel® Turbo Boost Technology | 2.0 |
| | Intel® Clear Video HD Technology (Intel® CVT | Ja |
| | Intel® Wireless Display (Intel® WiDi) | Ja |
| | Intel® Insider� | Ja |
| | Intel® Quick Sync Video Technology | Ja |
| | Intel® AES New Instructions (Intel® AES-NI) | Ja |
| | Intel® Anti-Theft Technology (Intel® AT) | Ja |
| | Intel® Rapid Storage Technology | Ja |
| | Intel® Virtualization Technology (Intel® VT) | VT-x |
| | Intel® ME Firmware-versie | 9.5 |
| |
Storage | Opslagkaarten afmetingen ondersteund | 2.5 " |
| | Opslag schijfinterface | Serial ATA II, Serial ATA III |
| | Aantal opslagkaarten ondersteund | 1 |
| | Compatible memory cards | Memory Stick (MS), MMC, MS PRO, SD |
| | Card reader integrated | Ja |
| |
Technische details | Processorfamilie | Intel |
| | Aantal ondersteunde processors | 1 |
| | Processor-productieproces | 22 nm |
| | Processor cores | 2 |
| | L3 cache | 3 MB |
| | Thermal Design Power (TDP) | 15 W |
| | Processor aantal threads | 4 |
| | Turbo-frequentie (max) | 2.6 GHz |
| | Aantal processorkernen | 2 |
| | Processorsocket | BGA1168 |
| | Maximaal ondersteunde CPU kloksnelheid | 2.6 GHz |
| | Compatibele processors | Core i5 |
| | Processor kloksnelheid | 1.6 GHz |
| | Processor model | i5-4200U |
| |
Uitbreidingsmodules | Mini PCI Express slots | 2 |
