Gigabyte B560M AORUS PRO moederbord Intel B560 Express LGA 1200 micro ATX

Informatie

Levertijd
Onbekend
Conditie
Nieuw
Voorraad
0

€ 196,67
Excl. btw: € 162,54
Niet op voorraad.

Beschrijving Gigabyte B560M AORUS PRO moederbord Intel B560 Express LGA 1200 micro ATX

DIRECT POWER DESIGN
B560M AORUS motherboard uses an 12+1 phases digital CPU power design which includes both digital PWM Controller and DrMOS. These 100% digital controller and additional 8 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU.

More efficient and cleaner power delivers to the CPU ensures stable performance under heavy loading.
- Digital PWM Controller to deliver appropriate voltage to the CPU.- Direct 12+1 Phases DrMOS without PWM Doublers, each power phase connects directly to the CPU, With capability to handle 600 Amps current in total.- All-solid capacitors to improve Transient response and minimize oscillation.- 8 Solid Pin CPU Power Connectors.

ADVANCED THERMAL SOLUTION
B560M AORUS uses high performance Fully Covered thermal design with high coverage MOSFET Heatsinks and thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers and gamers.

Fully Covered Thermal Design
High coverage MOSFET Heatsinks to improve thermal efficiency with better airflow and heat exchange.

Thick Thermal Pad
Thick 5W/mk thermal pad.

M.2 Thermal Guard
Built-in M.2 heatsink prevent high-speed, PCIe 4.0 SSDs from throttling due to overheating.

2X larger Surface
Increased surface area up to 2X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.

Real One-piece Build
TMOS is a TRUE single piece heatsink. Its one-piece design and larger surface drastically improve the cooling performance against competitors’ multi-piece design

Multi-cut Design
TMOS features several channels and inlets on the heatsink. This design allows for the air flow to go through which leads to a great improvement of the heat transfer performance.

AORUS M.2 Thermal GuardGIGABYTE Ultra-Efficient M.2 Thermal Guard
With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.
Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.

High Current Support
Each fan headers support PWM and DC fan and Water cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection

Precision Control
Up to 7 temperature/fan speed control points for precise fan curve

Dual Curve Mode
Slope/Stair dual mode for different user scenario

Smart Fan 6 BIOS UIImprove fan curve UI
We increase control points from 5 to 7 and larger fan speed graph for precise and easier fan curve control.Slope/Stair dual graph mode
Fan curve can be quickly switch with Slope and Stair modes for different user scenario. Slope is traditional and intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.Manual Input
For advanced users, we provide fan speed manual input for more precise control.EZ Tuning
Use can place 4 EZ Tuning points at rough temperature/fan speed, and Smart Fan 6 can quickly generate a fan curve.Fan curve profile
Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.

PERFORMANCE
With the best quality components and GIGABYTE R&D design capability, the B560M AORUS is a true beast among motherboards.

Dual PCIe 4.0/3.0 x4 M.2
GIGABYTE AORUS Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system's potential.

Intel 2.5GbE LAN Onboard2X Faster than ever
- Adoption of 2.5G LAN provide up to 2.5 GbE network connectivity, with at least 2 times faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience.- Support Multi-Gig(10/100/1000/2500Mbps) RJ-45 ethernet

USB Type-C® Front Panel Connector
Equipped with next generation connectivity AORUS Motherboards already support the chassis of the future. The onboard USB Type-C® header for USB 3.2 Gen1 makes access convenient when connecting a USB 3.2 Gen1 drive or charging your new mobile device.

High Quality Onboard Audio Design
Delivers high quality sound resolution and sound expansion to create the most realistic sound effects for professional gamers.

DEFINITIVE AESTHETICS
B560M AORUS PRO features RGB FUSION 2.0 and offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique and stylish.

Multi-Zone Light Show Design
Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.
With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style and show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.

GIGABYTE RGB Fusion APP
Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try and adjust colors and speeds for different modes, all this can be achieved away from the keyboard and monitor of their PC.

ULTRA DURABLE
GIGABYTE is reputable for its product durability and high quality manufacturing process. Needless to say, we use the best components we can find for the B560M AORUS motherboard and reinforce every slot to make each of them solid and durable.

Q-Flash Plus
Update the BIOS easily without installing the CPU, memory and graphics card.With GIGABYTE Q-Flash Plus, you don’t need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you’re good to go!

Ultra Durableâ„¢ PCIe ArmorIndustry Leading Ultra Durableâ„¢ PCIe Armor
The innovative one piece stainless steel shielding design from GIGABYTE reinforces the PCIe connectors to provide the extra strength required to support heavy graphics cards.

Solid Pin Power Connectors
AORUS motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.

Solid Pin Power connector advantages
- Larger contact area for electricity- More metal quantity to sustain higher power and generated heat- Ultra durable and longer lifespan

GIGABYTE BIOS & APP CENTER
Good software goes hand in hand with perfect hardware. GIGABYTE motherboard bundled several useful and intuitive software to help users to control every aspect of motherboard.

BIOSNew User Interface
All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.My Favorites
Add constantly used items into the favorite menu for quick access.Storage Information
Show all kinds of storage information including SATA, PCIE and M.2 interface.Changelog
List all changes before saving and exiting bios. Quickly review overall settings modification.Intuitive Load Line Curve
Clearly show each loadline calibration setting in an intuitive curve graph.

APP CENTER
GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities and drivers, you can choose any utility you want to install from APP CENTER and keep updated with the latest utilities and drivers version.

EasyTuneâ„¢
GIGABYTE's EasyTuneâ„¢ is a simple and easy-to-use interface that allows users to fine-tune their system settings or adjust system and memory clocks and voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.

System Information Viewer
GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior these are the possibilities of the System Information Viewer.

Specificaties Gigabyte B560M AORUS PRO moederbord Intel B560 Express LGA 1200 micro ATX

Processor
Intel
LGA 1200
Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel® Pentium®
LGA 1200 (Socket H5)
Geheugen
DDR4-SDRAM
4
128 GB
DIMM
Dual-channel
Ja
Ja
2133,2400,2666,2933,3000,3200 MHz
Ja
Opslag-controllers
M.2,SATA III
HDD & SSD
8
Grafisch
2-Way CrossFireX,Quad-GPU CrossFireX
4096 x 2304 Pixels
Ja
Interne aansluitingen
2
2
6
Ja
Ja
Ja
Ja
3
Ja
Ja
1
2
Ja
Ja
Aansluitingen achterzijde
6
2
1
1
1
1
1
1.4
1
1.2
6
Ja
USB Type-A, USB Type-C
Netwerk
Nee
Ja
2.5 Gigabit Ethernet
Kenmerken
PC
micro ATX
Intel
Intel B560 Express
7.1 kanalen
Ventilator, Temperatuur, Spanning
Windows 10 x64
Uitbreidingsmodules
1
2
2
BIOS
UEFI AMI
256 Mbit
5.0
Ja
2.7
2.7
Gewicht en omvang
244 mm
244 mm
Inhoud van de verpakking
Norton Internet Security, cFosSpeed"

Algemene kenmerken

SKU
B560M AORUS PRO-rev
EAN
4719331814991
Merk
Gigabyte

Product kenmerken

Soort
Gaming
