| Processor |
| L3 cache | 12 MB |
| Processorfamilie | 2-CPU / Xeon SP |
| Aantal processorkernen | 8-Core |
| Frequentie van processor | 2.8 GHz |
| Max. aantal SMP-processoren | 2 |
| Processor socket | P4 / LGA4189 |
| Chipset moederbord | Intel C621A |
| Maximale turbofrequentie van processor | 3.6 GHz |
| Algemeen |
| Processormodel | Intel Xeon Silver 4309Y / 2.8 GHz |
| Besturingssysteem | Geen operating system |
| Prestatie |
| Markt positionering | SERVER 6000 |
| Compatibele besturingssystemen | Windows Server 2022 Windows Server 2019 |
| Aantal kanalen | 8 |
| Geheugen |
| Intern geheugen | 64 GB |
| Maximum intern geheugen | 4096 GB |
| Intern geheugentype | REG DDR4 DIMM met ECC |
| Geheugenslots | 16x DDR4 PC3200/2933, REG ECC |
| Geheugen kanaal | 8-Channel-Memory-Architecture |
| Opslagmedia |
| Soort optische drive | Optional |
| Soorten RAID | RAID 1 |
| Aantal storage drives geïnstalleerd | 2 stuk(s) |
| Interne drive bays | 4x 3.5/2.5 optioneel 8x 3.5/2.5 |
| Totale opslagcapaciteit | 3800 GB |
| SSD interfaces | SATA 6Gb/s |
| HDD capaciteit | 2x 1.9 TB SSD |
| Opslagmedia-type | SSD |
| Design |
| Certificering | CE, productie volgens ISO9001 in Duitsland |
| Rack-montage | staande behuizing / 5U |
| Type behuizing | Pedestal / Tower - optioneel convertible |
| Energie |
| Stroombron | Power supply - redundant |
| Redundante voeding | Ja |
| Maximaal ingangsvermogen | 800 W |
| Aantal voedingen | 2 stuk(s) |
| Muis |
| Inclusief muis | optioneel |
| Toetsenbord |
| Toetsenbord formaat | Optioneel |
| Netwerk |
| Ethernet LAN | geïntegreerd |
| LAN controller | 2x Intel X550 2x Intel I210 |
| Bekabelingstechnologie | 2x 10 GbE (RJ45) 2x 1 GbE (RJ45) |
| Overige specificaties |
| Aantal drive bays | Slot 1: PCIe 4.0 x16 (CPU1) Slot 2: PCIe 4.0 x16 (CPU2) Slot 3: PCIe 4.0 x16 (CPU1) Slot 4: PCIe 4.0 x16 (CPU2) Slot 5: PCIe 4.0 x16 (CPU1) Slot 6: PCIe 4.0 x8 (CPU2) |
| Interne schijfposities | 3x 5.25 1x 3.5 |
| Interface | 1x VGA 1x USB 3.2 Gen2 6x USB 3.2 Gen1 (2x front) 2x LAN (RJ-45) option: 1x serial |
| Merk moederbord | Supermicro X12DAI-N6 |
| Beheer op afstand | Ja |
| Harde schijf-controller | Broadcom MegaRAID 9560-8i |
| Technische details |
| Land | Internationaal |
| Optionele on-site service | 24h On-Site-Service 24h On-Site-Service + DMR + Premium |
| Gewicht en omvang |
| Hoogte | 42.5 |
| Breedte | 22 cm |
| Diepte | 66 cm |
| Gewicht | 30.5 kg |
| Koeling |
| Type koeling | Actief |
| Grafisch |
| Aantal displayports grafische adapter | VGA |
| Grafische adapter | Aspeed AST2600 |
| Eisen aan de omgeving |
| Bedrijfstemperatuur (T-T) | 10 °C - 35 °C (aanbeveling: 20 °C - 22 °C) |
| Aanbevolen relatieve luchtvochtigheid bij gebruik | 10-75% (niet condenserend) |
